Case IH Farmall C Upgrade: More power, weight & precision
The Case IH Farmall C, well known across New Zealand, has just seen an upgrade including a new look, increased weight and hydraulic power, and a cab overhaul.
The design should offer better access to low doorways, buildings and around yards, meaning the machine should be well suited to livestock operations or around grading lines and packhouses.
The machine is powered by a 74hp (54.6kW) four-cylinder engine, driving through a single-range 30km/h hydrostatic transmission, while a mechanical electroproportional hydraulic system features a gear pump providing 80 l/min of oil flow at 210 bar pressure.
Maximum lift capacity is 2600kg, with a maximum lift height of 5.9m, an increase of 200mm over its predecessor. Headstock rotation is 155 degrees, aimed at greater dump angles and quicker unloading times.
Key dimensions are an overall length of just over 4m, combined with a wheelbase of 2.52m, said to deliver exceptional stability when lifting heavy loads or travelling at speed. Enhanced manoeuvrability is achieved by a 1.89m overall width, 1.93m height and a turn radius of 3.25m. Despite the narrow overall width, the 960mm-wide cab is broader than the model it replaces, providing increased operator comfort.
A range of new options includes a factory- fitted trailer hitch and hydraulic or pneumatic trailer braking. Carbon cabin filters for the ventilation system to protect operator health in particularly dusty conditions.
An optional telematics package provides identification of location, plus automated monitoring and recording of operating and performance data. Via the Case IH FieldOps app, data from the 626 and all connected machines in a fleet can be monitored via any online smart device or PC.
