Hose runner saves time and effort
Rakaia-based equipment manufacturer Pluck’s Engineering will soon start production of a new machine designed to simplify the deployment and retrieval of temporary water troughs used in winter break feeding.
The new XDisc 710, with a cutting width of 7.1 metres, has been developed to utilise the full potential of a powerful forager more efficiently, using cutter-bar technology based on the EasyCut mower technology already employed in the XDisc 620.
In operation, the speed of the 900mm diameter integral feed auger can be optimally adjusted to the intake speed of the forage harvester in three stages, depending on the required cutting length of the crop.
A clever option, available solely for the Big X Series, is the integrated header transport chassis that eliminates the need for a separate transport trailer, so significantly reducing changeover times between paddock or site moves.
The transport chassis is equipped with a single axle on the right-hand side of the header, with the drawbar, with its folding support jack located on the opposite side. In operation, when the hydraulic system has been coupled and the header raised, the driver swivels the drawbar and the axle of the running gear directly from the cab.
In the paddock, both transport kit components hydraulically swivel behind the header, with the process is reversed for transport, before the header trailer is attached to the forage harvester’s tow coupling.
Other XDisc 710 options include vertical side knives, which are also offered on the XDisc 620, raised and lowered individually from the cab, to provide blockage-free cutting when working in tangled or heavily lodged crops.
