GPS in control
In a move that will make harvesting operations easier, particularly in odd-shaped paddocks, Kuhn has announced that GPS section control is now available on the FC 9330 RA mower conditioner, the GA 13231, and GA 15231 four-rotor rakes.
It has four rotors, each fitted with 11 heavy duty tine arms and four tynes per arm. Each unit is carried by four large diameter pivoting wheels that ensure accurate ground following, greater stability and the potential for high working speeds.
Working height is adjusted hydraulically from the seat and on the move and should reduce the risk of soil contamination.
The drive to the rotors is hydraulically controlled and offers the unique ability to increase front rotor speed by 20% for use in light crops, but more importantly removes the typical PTO shaft set-up that is prone to damage in semi-mounted configurations.
Each rotor has the Masterdrive GIII gearbox that allows 3-D pivoting system and 200 hour service intervals
Windrow formation can be adjusted hydraulically from 1.5 to 2.4m width, and each rotor can be lifted individually for a good finish and greater clearance when operating in undulating terrain.
Ease of use is further enhanced by an ISOBUS compatible VT50 control terminal, which can be used to pre-programme the rotor lift sequence for single touch headland turns. The rear ‘touchdown’ of each rotor ensures there is no soil contamination.
Transport width is 3m and transport height is under 4m. PTO power requirement is a thrifty 95hp.
